Metrology: 110GHz Single Sweep (N5247A PNA-X & E5061B)

What is it?
Vector Network Analyzer

Manufacturer: Agilent

Model Name: N5247A PNA-X

Applications: RF Network analyzers are used to measure components, devices, circuits, and sub-assemblies. An RF network analyzer will contain both a source and multiple receivers. It will display amplitude and often phase information (frequency or power sweeps) and normally in a ratio format.

Instrument Overview: The RF Vector Network Analyzer, VNA is a test instrument that measures the response of a network as vector: real & imaginary parameters (Scattering parameters) so that its performance can be characterised.

Technical features and specifications:
10 MHz to 110 GHz

Charges:
Nil

Instrument Manufacturer URL: https://www.keysight.com/

Detailed Specifications:
https://www.keysight.com/sg/en/products.html
