Metrology: A MEMS Measurement System

What is it?
Impedance spectroscopy characterisation system

Manufacturer: Keysight

Model Name: Keysight B1500A Semiconductor Device Analyzer E4990A-120 20Hz to 120MHz Impedance Analyzer , E4980A 2 MHz Precision LCR Meter, E5061B Network Analyzer, N9020A MXA Signal Analyzer, DSOS404A Oscilloscope - Infiniium S Series 4 GHz 4 CH, Cascade Microtech Summit 11000 Probe Station

Applications: For electrical characterisaiton of devices in dc and impedance parameters

Instrument Overview: Impedance spectroscopy characterisation+K23 system able to measure DC parameter, impedance, Measurement Instrumentation

Technical features and specifications:
Measurement electrical DC and impedance parameters

Charges:
Nil

Instrument Manufacturer URL: https://www.keysight.com/sg/en/home.html

Detailed Specifications:
https://www.keysight.com/sg/en/products.html
