What is it?
Atomic Force Microscope for measuring nano-structure
Manufacturer: Bruker
Model Name: Dimension V 3100
Applications: Applications of atomic force microscopy (AFM) include measurements of nano-scale surface topography in semiconductor, precision engineering, photonics and additive manufacturing industrial sectors.
Instrument Overview: Atomic Force Microscope (AFM) with contact & non-contact mode is one of the most powerful tools for measurement of surface texture of micro- and nano-structures at sub-nanometre resolution with wide applications in nanotechnology. Acoustical enclosure and anti-vibration are installed to ensure the measurement stability preventing from external disturbances.
Technical features and specifications:
Measurement volume: 90 μm × 90 μm × 8 μm (x, y and z axes)
Open loop noise level in z axis :0.05 nm (RMS — the root mean square average of the noise)
Close loop noise level in z axis: 0.06 nm (RMS)
Open loop noise level in x & y axes: 1.5 nm (RMS)
Close loop noise level in x & axes: 1.8 nm (RMS)
Charges:
Subjected to actual measurement tasks
Instrument Manufacturer URL: https://www.bruker.com
Detailed Specifications:
-
