Metrology: CA - Ultra QV CMM

What is it?
An ultra precise vision based CNC measuring machine for dimension measruements

Manufacturer: Mitutoyo Corporation

Model Name: Ultra QV404

Applications: Used as a standard for 1D/2D dimensional measurement in industries of Precision Engineering, Aerospace, Oil & Gas, Caltest, Electronics

Instrument Overview: An image-based optical tracking system equipped with video cameras for calibrations of high quality scales with sub-µm uncertainty; Built on an air-bearing kinematics structure with ball screw driven and uses glass encoders with thermal expansion coefficient of nearly zero as the length measuring systems for all three axes; Traceable against reference scale or laser interferometer

Technical features and specifications:
Measuring resolution: 10 nm 1D measuring uncertainty: (0.25 µm + L/1e6) 2D measurement uncertainty: (0.50 µm + 2L/1e6 Repeatability: 0.2 µm (3 sigma­­­­)

Charges:
-

Instrument Manufacturer URL: https://www2.mitutoyo.co.jp/eng/

Detailed Specifications:
https://www.mitutoyo.com/webfoo/wp-content/uploads/2118_Quick_Vision.pdf
